Little Giant 540005 CP1-115 Evaporative Cooler Pump 115/127V

Little Giant 540005 CP1-115 Evaporative Cooler Pump 115/127V 1/70HP 4 ft Cord With Plug

• 1/70 HP, 307 GPH at 1-Inch, 115/127V
• Heavy duty cocentric fan-cooled motor
• Thermal overload protection
• Universal mounting configurations
• 90 degree barbed elbow with bleed-off

Description
"LITTLE GIANT" EVAPORATIVE COOLER PUMP Designed for reliability in recirculating applications as replacement units for orginal equipment. For use in evaporative coolers, displays, laboratories, water transfer and other applications. Heavy Duty Concentric Fan-cooled Motor Thermal Overload Protection Corrosion-resistant One-piece Steel Motor Shaft Universal Mounting Configurations Moisture-proof Windings Oversized Sleeve Bearings with Large Oil Reservoir 90 Degree Barbed Elbow with Bleed-off Low Pump Down and Recovery Levels Grounded Plug For coolers up to 6500 CFM Flame Retardant Housing Snap-off Volute Plate for Easy Cleaning Mesh Debris Screen. CP1-115 1/70 hp 307 gph Heavy-Duty Evaporative Cooler Pump w/ 1/2", 5/8", 3/4" Discharge & 4 ft Cord, 115/127V-60Hz

Features:

• Heavy-duty, dual copper coil, concentric fan-cooled motor
• Oversized sleeve bearings
• Moisture proof windings
• Thermally protected
• Corrosion resistant steel shaft
• Mesh inlet debris filter screen
• Removable base plate for easy cleaning
• Flame retardant housing and motor cover
• Removable and locking 90º discharge adapter with 3/8" O.D. bleed-off port
• Discharge designed for 1/2" and 5/8" tubing
• Low level pump down and recovery
• 3-way universal mounting configuration:
• Top/motor cap mounting
• Column mounting slots (use existing equipment bracket)
• Side mounting using steel bracket (included)
• Liquid temperature up to 120 ºF
• 4 ft power cord with 3-prong plug

Application:
For use in evaporative coolers, sales displays, laboratories, water bath circulation and many other uses. Ideal as a universal OEM replacement pump

Construction:

• Motor: Heavy duty fan cooled
• Housing: Flame retardant thermal plastic
• Motor cover: Flame retardant thermal plastic
• Volute: Flame retardant thermal plastic
• Impeller: Polyester
• Mounting bracket: Galvanized steel

Specification
