Taco 009-F5Y 230V Cast Iron 1/8 hp Circulator Pump

Taco 009-F5Y 230V Cast Iron 1/8 hp Circulator Pump

$375.25 USD
$375.25 USD
Sale Sold out

Taco 009-F5Y 230V Outdoor Wood Furnace Circulator Pump

The Taco 009 is designed for a wide range of Residential/Light Commercial higher-head/lower-flow water circulating applications. Typical uses include Hydronic heating, Radiant In-Floor/Panel Heating and closed-loop Solar heating systems. The unique replaceable cartridge contains all of the moving parts and allows for easy service, instead of replacing the entire circulator. Compact, direct-drive, low power consumption design is ideal for high-efficiency jobs.

Features
  • Standard High Capacity Output
  • Compact Design
  • Quiet, Efficient Operation
  • Unique Replaceable Cartridge Design – Field Serviceable
  • Direct Drive-Low Power Consumption
  • Self-Lubricating
  • No Mechanical Seal
  • Unmatched Reliability --Maintenance Free
  • Universal Flange-to-Flange Dimensions
  • Cast Iron or Bronze Construction

Typical Applications

  • Hydronic Heating
  • Radiant In-Floor/Panel Heating
  • Closed-Loop Solar Heating Systems

Performance Data
Flow Range: 0-8 GPM
Head Range: 0-34 Feet
Minimum Fluid Temperature: 40º F (4º C)
Maximum Fluid Temperature: 230º F (110º C)
Maximum Working Pressure: 125 PSI
Connection Sizes: 3/4”, 1”, 1-1/4”, 1-1/2” Flanged

Electrical Data

  • 230 Volts
  • 60 Hz
  • 1 Phase
  • 1.40 Amps
  • 3250 RPM
  • 1/8 HP
