White Rodgers 1300 Series 1361-102 Hydronic Zone Valve

1300 Series valves for zoning systems up to 50 PSI operate quietly and efficiently providing years of reliable service

• Self-aligning barrel-type valve stem design
• Made of a corrosion-resistant stainless steel
• Motor can be removed from valve assembly without draining system
• Built-in auxiliary contacts to control burner or circulator relay
• Automatic recycling manual operator shows valve position at all times
• Screw terminal wiring panel for added convenience

• Size 3/4” Tubing (I.D.)
• Thermostat Type 3 - Wire
• Time Cycle Open: 45 secondsClose: 60 seconds
• Pressure Maximum Differential Across Valve - 15 PSI
• Maximum Fluid Temp. 240°F(116°C)
• Pressure 50 PSI (max)
• Flow Cv 23.5 (GPM @ 1 PSI drop) Equivalent to 2.5 Ft. of Tubing
• Electrical Rating 24 Vac, 1311 0.4A, 1361 0.2A, Aux Switch 2.0A
